Sagola X 4100 Pressure Spray Gun

$585.00

The X 4100 is a great light weight industrial pressure spray gun.

SKU: Sagola 4100 Xtreme Pressure Category: Tags: ,
Clear

Description

Sagola X 4100 Pressure Spray Gun

The Sagola X 4100 Pressure Gun is designed to be ergonomic and easy to use. This gun needs minimal maintenance with no seals or plastic parts in the product area. You can use any air cap and needle nozzle allowing for 20+ variations. Each kit is supplied with its own needle nozzle and air cap.

  • Interchangeable Parts
  • Consistent high quality finishes
  • Low Maintenance

X 4100 Manual

Needle Nozzle & Air Caps Ideal for use with: Working Pressure Range Typical Paint Pressure Air Consumption at 2bar Application Distance
1.00mm
[765 Air Cap]
Basecoats 1.8 – 2.5bar
(26 – 36psi)
0.5 – 1.0bar
(7 – 14.5psi)
315LPM
(11.12CFM)
18 – 20cm
(7 – 7.9”)
1.40mm
[765 Air Cap]
Wash Primers 2.0 – 2.5bar
(29 – 36psi)
1.0 – 1.5bar
(14.5 – 22psi)
315LPM
(11.12CFM)
18 – 20cm
(7 – 7.9”)
1.00mm
[777 Air Cap]
MS Clear coats 2.0 – 2.5bar
(29 – 36psi)
0.8 – 1.5 bar
(11.6 – 22psi)
345LPM
(12.18CFM)
18 – 20cm
(7 – 7.9”)
1.20mm
[777 Air Cap]
HS Clear coats
UHS Clear coats
Single Stage
2.0 – 2.5bar
(29 – 36psi)
0.8 – 1.5 bar
(11.6 – 22psi)
345LPM
(12.18CFM)
18 – 20cm
(7 – 7.9”)
1.00mm
[XT03 Air Cap]
Basecoats 1.8 – 2.2bar
(26 – 32psi)
0.5 – 1.0bar
(7 – 14.5psi)
460LPM
(16.24CFM)
12 – 15cm
(4.7 – 5.9”)
1.20mm
[XT03 Air Cap]
Wash Primers 2.0 – 2.5bar
(29 – 36psi)
1.0 – 1.5bar
(14.5 – 22psi)
460LPM
(16.24CFM)
12 – 15cm
(4.7 – 5.9”)
1.00mm
[XT01B Air Cap]
Basecoats 1.8 – 2.2bar
(26 – 32psi)
0.5 – 1.0bar
(7 – 14.5psi)
295LPM
(10.42CFM)
18 – 20cm
(7 – 7.9”)
1.20mm
[XT01B Air Cap]
Wash Primers 2.0 – 2.5bar
(29 – 36psi)
1.0 – 1.5bar
(14.5 – 22psi)
295LPM
(10.42CFM)
18 – 20cm
(7 – 7.9”)
1.40mm
[XT01B Air Cap]
Primers & Fillers 2.0 – 2.5bar
(29 – 36psi)
2.0 – 2.5bar
(29.0 – 36psi)
295LPM
(10.42CFM)
18 – 20cm
(7 – 7.9”)
1.40mm
[3030 HVLP Air Cap]
Primers & Fillers 2.0 – 2.5bar
(29 – 36psi)
1.0 – 2.0bar
(14.5 – 29.0psi)
514LPM
(18.15CFM)
12 – 15cm
(4.7 – 5.9”)
1.00mm
[Super VIT Air Cap]
Basecoats 1.8 – 2.2bar
(26 – 32psi)
0.5 – 1.0bar
(7 – 14.5psi)
380LPM
(13.42CFM)
18 – 20cm
(7 – 7.9”)
1.20mm
[Super VIT Air Cap]
Wash Primers 2.0 – 2.5bar
(29 – 36psi)
1.0 – 1.5bar
(14.5 – 22psi)
380LPM
(13.42CFM)
18 – 20cm
(7 – 7.9”)
1.40mm
[Super VIT Air Cap]
Primers & Fillers 2.0 – 2.5bar
(29 – 36psi)
2.0 – 2.5bar
(29.0 – 36psi)
380LPM
(13.42CFM)
18 – 20cm
(7 – 7.9”)

Additional information

Weight N/A
Air Cap

765 Air Cap, 777 Air Cap, XT03 Air Cap, XT01B Air Cap, 3030 HVLP Air Cap, Super VIT Air Cap, 20A Air Cap

NEEDLE/NOZZLE

1.00mm, 1.20mm, 1.30mm, 1.40mm, 1.80mm

Dimensions

20 x 17 x 4.2cm (7.87 x 6.7 x 1.65”)

Weight (with Filter Holder)

645g (1.42lbs)

Air Inlet Couplings

6.35mm (1/4”) Male BSP

Paint Filter

80 mesh

Product Inlet Coupling

9.5mm (3/8”) Male BSP

Design Pressure

8bar (116psi)

Working Pressure

2 – 3bar (29 – 43.5psi)

Sound Pressure Level (Average)

80 dB

Compliance

ATEX II 2G x (Directive 2014/34/EU)
