Sagola Mini Xtreme Spray Gun

$436.25$449.50

The Mini Xtreme is the perfect gun for spot repair with its high transfer efficiency and low air consumption.

SKU: Sagola Mini Xtreme Category: Tags: ,
Clear

Description

Sagola Mini Xtreme

Save paint and time with the Mini Xtreme’s high product transfer efficiency that provides great coverage. This gun, with its multiple air caps & needle nozzles will perfect every spot repair and high detail project. Get the best finish possible on detailed projects with this light and ergonomic gun.

Each gun comes ready to paint including a needle nozzle kit, air cap, cup and cleaning equipment. Along with the initial kit, every part is available for sale allowing for 15+ variations all with the purchase of one gun.

  • Interchangeable Parts
  • Consistent high quality finishes
  • Low Maintenance

Sagola Mini Xtreme Manual

Sagola Mini Xtreme Exploded View

Mini Xtreme Diagram 1

Guaranteed Consistent Quality Finish

1. Optimum paint flow with a fast and smooth applications. Interchangeable steel nozzles.

2. Precisely measure flow measurement with the product regulator and its indicator ring.

3. No metallic or plastic external parts used in the air distribution. This makes the cleaning process easier.

4. Save paint with the high precision “soft flow” air valve that allows accurate setup of air pressure.

5. Interchangeable aluminum air caps with unique colors.

Mini Xtreme Diagram 2

Simple Maintenance

6. Manufactured without gaskets or seals in the product area. No air diffusers, blind chambers or threads in contact with the paint/product/material. Just metal in contact with metal. Extremely easy to clean and maintain.

7. The only spray gun in the refinishing market with one single piece automatic paint packing gland minimizing potential damage and breakage and easier to remove when cleaning the gun.

Mini Xtreme Diagram 3

Built to be Easy

8. Ergonomic anodized forged aluminum body that is perfectly balanced.

9. Stainless steel trigger designed to reduce operator discomfort and fatigue. Smooth trigger action.

10. Color coded identifiers that allow for easy organization of spray guns.

11. Balanced and ergonomic handle.

12. Fan width regulator.

Sagola Spray Gun Kit Contents

Sagola Mini Xtreme kit Contents

Each Mini Xtreme kit is supplied with:

  • Aircap, Needle & Nozzle Kit
  • 125ml or 500ml reusable plastic gravity cup with filter
  • Wrench for removing & fitting the nozzle plus other service needs
  • Color coded rings for organizing multiple guns
  • Key assembly for changing the air valve
Mini Aqua Air Cap Aqua Air Cap Specifications:
Enhanced application of waterborne products. Even distribution of paint regardless of the level of viscosity.

Needle & Nozzle Ideal for use with: Working Pressure Range Air Consumption 29 PSI Output Flow (average) Application Distance Fan Width (Max) Supplied Cup
0.80mm Solvent Based Coats
Spot Repair
1.0 – 1.5bar
(15 – 22psi)
190LPM
(6.71CFM)
49g/min
(1.7oz/min)
18 – 20cm
(7 – 7.9”)
110mm
(4.33”)
125ml (White)
1.00mm Solvent Based Coats
Waterborne Basecoats
Spot Repair
1.0 – 1.5bar
(15 – 22psi)
190LPM
(6.71CFM)
97g/min
(3.4oz/min)
18 – 20cm
(7 – 7.9”)
195mm
(7.68”)
125ml (White)
1.20mm Solvent Based Coats
Waterborne Basecoats
UV Primers
Spot Repair
1.2 – 2.0bar
(17 – 29psi)
190LPM
(6.71CFM)
162g/min
(5.7oz/min)
18 – 20cm
(7 – 7.9”)
18 – 20cm
(7 – 7.9”)
125ml (Black)



Mini EPA Air Cap EPA Air Cap Specifications:
Ideal for high speed low viscosity applications. Ideal for any type of clearcoat.

Needle & Nozzle Ideal for use with: Working Pressure Range Air Consumption 29 PSI Output Flow (average) Application Distance Fan Width (Max) Supplied Cup
0.80mm Solvent Based Coats
Spot Repair
1.0 – 1.5bar
(15 – 22psi)
190LPM
(6.71CFM)
49g/min
(1.7oz/min)
18 – 20cm
(7 – 7.9”)
110mm
(4.33”)
500ml (White)
1.00mm Express Drying Clear Coats
HS Clear Coats
Spot Repair
1.0 – 1.5bar
(15 – 22psi)
190LPM
(6.71CFM)
97g/min
(3.4oz/min)
18 – 20cm
(7 – 7.9”)
195mm
(7.68”)
500ml (White)
1.00mm UHS Clear Coats
Spot Repair
1.2 – 2.0bar
(17 – 29psi)
190LPM
(6.71CFM)
162g/min
(5.7oz/min)
18 – 20cm
(7 – 7.9”)
260mm
(10.24”)
500ml (White)



Mini HVLP Air Cap HVLP Air Cap Specifications:
For use with high volume and low pressure applications. Excels at waterborne or express drying products.

Needle & Nozzle Ideal for use with: Working Pressure Range Air Consumption 29 PSI Output Flow (average) Application Distance Fan Width (Max) Supplied Cup
1.00mm Primers
Sanding Surfacers
Spot Repair
1.8 – 2.0bar
(26 – 29psi)
325LPM
(11.48CFM)
80g/min
(2.8oz/min)
10-15cm
(3.9 – 5.9”)
155mm (6.10”) 125ml (White)
1.20mm Primers
Sanding Surfacers
Spot Repair
1.8 – 2.0bar
(26 – 29psi)
325LPM
(11.48CFM)
123g/min
(4.3oz/min)
10-15cm
(3.9 – 5.9”)
195mm
(7.68”)
125ml (White)
1.30mm Primers
Sanding Surfacers
Spot Repair
1.8 – 2.0bar
(26 – 29psi)
325LPM
(11.48CFM)
133g/min
(4.7oz/min)
10-15cm
(3.9 – 5.9”)
215mm
(8.46”)
500ml (White)



Mini Tech Air Cap Tech Air Cap Specifications:
The ideal air cap for express drying clearcoats and one coat systems.

Needle & Nozzle Ideal for use with: Working Pressure Range Air Consumption 29 PSI Output Flow (average) Application Distance Fan Width (Max) Supplied Cup
0.60mm Low Viscosity Primers
Spot Repair
0.5 – 1.0bar
(7.25 – 14.5psi)
52LPM
(11.12CFM)
96g/min
(3.39oz/min)
18 – 20cm
(7 – 7.9”)
50mm
(1.96”)
500ml (White)

Additional information

Weight 2 lbs
Air Cap

Aqua Air Cap, EPA Air Cap, HVLP Air Cap, Tech Air Cap

Needle/Nozzle

0.60mm, 0.80mm, 1.00mm, 1.20mm, 1.30mm

Cup Capacity

125ml (4.23fl oz) or 500ml (16.9fl oz)

Cup Type

Removable Anti-Drip System

Air Inlet Couplings

6.35mm (1/4”) Male BSP

Paint Filter

100 mesh

Weight with Supplied Cup

125ml Cup: 445.5g (0.98lbs), 500ml Cup: 552.75g (1.22lbs)

Weight without Cup

365g (0.80lbs)

Dimensions without Cup (W x D x H)

156.4 x 18 x 158.8mm (6.16 x 0.71 x 6.25")

Sound Pressure Level (Average)

80 dB

Compliance

ATEX II 2G T60°C X (Directive 94/9/CE)
